Features

  • Requires the use of Terminal Fuse Blocks PN 5191 or PN 2151 - do not mount the fuse directly to the battery terminal
  • Interrupt rating satisfies ABYC requirements for DC Main circuit protection on large battery banks
  • Ignition protected—safe for installation aboard gasoline powered boats
  • Clear window—visual indication of blown condition
  • Colour coded for each amperage



Specifications
Amperage 50A
Ignition Protected Yes
Maximum Voltage 58V DC
Interrupt Capacity 10000A @ 14V DC
5000A @ 32V DC
2000A @ 58V DC
Weight 0.06lb (0.03 kg)



Trip Delay Curve



SKU BSS.5176
Model # 5176B
UPC/EAN 632085051761
Brand Blue Sea Systems
Shipping Weight 0.0300kg
