INJECTION-MOULDED POLYPROPYLENE CONE

By using a translucent cone, consistent multi-colour illumination are incorporated into the system. It also produces defined, high-resolution low-frequencies from the excellent self-damping and bass reproduction.

LARGE DIAMETER VOICE COIL

With an increase in real power and efficiency, the large-diameter voice coil delivers a truly high-quality sound experience.

HIGH-QUALITY BASKET CONSTRUCTION

The basket is constructed using high-quality engineered plastics to deliver enhanced durability when exposed to the marine environment.

General


Physical dimensions
(Diameter x Depth)
Classic: 10.79" x 5.59" (274 x 142 mm)
Sports: 10.79" x 5.79" (274 x 147 mm)
Water and dust rating IP65
Speaker size 10"
Peak power (Watts) 600 W
RMS power (Watts) 120 W
Sensitivity (1 W / 1 m) 87 dB
Magnetic structure 41 oz
Frequency response 30 Hz - 2 kHz
Nominal impedance 4 ohms
Recommended amplifier power (RMS) 40 - 300 W
LED lighting Yes - RGB (XS-SL10SPGW)
LED supply voltage 10.8-16 VDC (XS-SL10SPGW)
LED load current @ 14.4 VDC 150 mA (XS-SL10SPGW)
Operating temperature range 32° to 122° F (0° to 50° C)
Voice coil diameter 1.5"
Cone material Polypropylene cone with rubber surround
Compass-safe distance 146" (370 cm)
Warranty 3 years

Mounting dimensions


Mounting diameter clearance 8.78" (223 mm)
Mounting depth clearance 4.45" (113 mm)

Optimum enclosure recommendations


Sealed enclosure volume1 1.4 cubic ft (40 L)

1 Fully filled with absorption material

SKU FUS.010-02198-01
Model # 010-02198-01
UPC/EAN 0753759274986
Brand Fusion
Shipping Weight 4.0800kg
