See what’s happening below the water.

ULTRA HIGH-DEFINITION CLEARVÜ SCANNING SONAR

Get brilliant image clarity of structure and fish below your boat at greater depths than other high-frequency scanning sonars. It puts more power on targets via a downward-facing element.

ULTRA HIGH-DEFINITION SIDEVÜ SCANNING SONAR

See everything the first time with stunningly clear images of structure and fish off to the sides of your boat. SideVü sonar now has 20% greater range at 1,000 kHz, so you can see even farther than before.

MULTIPLE SCANNING SONAR FREQUENCIES

Use the perfect frequency for the waters you’re fishing. This transducer delivers 455 kHz, 800 kHz and 1,000 kHz for top performances at all depths.

VIVID COLOUR PALETTES

High-contrast vivid scanning sonar colour palettes make it easier than ever to distinguish targets and structure.

MOUNTING OPTIONS

Everyone’s setup is different. That’s why we’ve included transom and trolling motor mounting hardware.

OPTIONAL CHIRP TRADITIONAL SONAR

Use a Y-cable (sold separately) to pair with a Garmin GT8HW-IH or Garmin GT15M-IH transducer (each sold separately) to add high wide CHIRP traditional sonar for remarkably clear target separation.

Features

Misc

Dimensions (without mount): 218.5 mm x 51.8 mm x 27.7 mm

Transducer cable length 7.62 m
Transducer depth/speed/temperature Depth and temperature
Transducer power ClearVü/SideVü 500 W
Transducer frequency ClearVü/SideVü 455 kHz (425-485 kHz), 800 kHz (790-850 kHz), 1000 kHz (940-1100)
Transducer supported deadrise/transom angles        0°-70° degree transom
Transducer maximum depth ClearVü: 122 m; SideVü: 152 m
Transducer number of pins 12
Transducer beamwidth

ClearVü
0.52 x 52 @ 1000 kHz
0.64 x 35 @ 800 kHz
1.1 x 52 @ 455 kHz

SideVü
0.52 x 52 @ 1000 kHz

SKU GAR.010-13072-00
Model # 010-13072-00
UPC/EAN 0753759269319
Brand Garmin
Shipping Weight 1.3600kg
