Head out confidently.

MULTI-BAND GNSS AND MULTI-CONSTELLATION

The multi-band GNSS (L1 and L5 GPS) and multi-constellation (GPS, Galileo1, GLONASS and BeiDou1) receiver delivers precise positioning2.

BOAT HEAVE AND MORE

Get reliable, accurate boat heave, pitch and roll information — even in rough waters.

BUILT-IN ATTITUDE HEADING REFERENCE SYSTEM (AHRS)

The built-in AHRS delivers better GPS heading information at high speeds.

ACCURATE HEADING DATA

Multiple receivers deliver heading accuracy within 2 degrees. Because it uses satellite signals, you don’t have to worry about magnetic interference.

PRIMARY SENSOR ACROSS MULTIPLE SYSTEMS

You can use MSC 10 as the primary sensor for autopilots and other onboard systems that need accurate heading information.

NMEA 2000® NETWORK COMPATIBLE

Get heading, pitch, roll and heave information delivered straight to your compatible Garmin chart plotter via the NMEA 2000 network.

Built for a better boating experience.

EASY TO INSTALL

This compact device is simple to install and easily integrates into your Garmin marine ecosystem.

10 HZ UPDATE RATE

Get better, more detailed tracking information, thanks to the 10 Hz position update rate.

BACKUP HEADING SENSOR

In the extremely rare case that you lose a satellite signal, MSC 10 will seamlessly transition from GPS-based to magnetometer-based heading3.

Supported when available.

< 1 metre CEP, < 3 metres 95%

Magnetometer calibration required for backup magnetic heading support.

Features

productSpecMisc
  • Dimensions (W x D x H): 6.1″ x 13.1″ x 3.0″ (155.5 x 333.6 x 76.2 mm)
  • Weight: 28.6 oz (810 g)
  • Cable length: 19 ft 8 in (6 m)
  • Temperature range: 5° to 158° F (-15° to 70° C)
  • Case material: Glue sealed, high-impact-plastic alloy; waterproof to IPX7
  • Compass-safe distance: 0″ (0 mm)
  • Power source input: 9-32 Vdc, unregulated
  • Input current: 180 mA at 12 Vdc
  • NMEA 2000 Load Equivalency Number (LEN): 6 (300 mA max)
  • Position accuracy, typical marine use: < 1 metre, CEP, < 3 metres, 95%
  • Heading accuracy: 2° RMS
  • Heave accuracy: 8 cm RMS
SKU GAR.010-02407-00
Model # 010-02407-00
UPC/EAN 0753759254971
Brand Garmin
Shipping Weight 2.2900kg
