The Hikvision HiLook IPC-B261H-MU 6MP Bullet Camera delivers exceptional image quality with its 6 MP resolution, ensuring clear and detailed footage in various lighting conditions. The camera’s 120 dB Wide Dynamic Range (WDR) technology guarantees effective imaging even in scenes with strong backlight, providing consistent clarity in all environments.

Key Features

  • 6 MP high-quality imaging
  • Efficient H.265+ video compression
  • 120 dB Wide Dynamic Range (WDR) for clear imaging in challenging lighting conditions
  • AI-based human and vehicle classification
  • Built-in microphone
  • IP67-rated
  • Power over Ethernet (PoE)
  • IR range of up to 40 metres for clear night vision with smart supplement light
  • Fixed 2.8 mm lens with a wide horizontal field of view of 107°
  • Supports multiple video compression formats including H.265, H.264, and MJPEG
  • Motion detection and video tampering alarm
  • Perimeter protection with line crossing detection and intrusion detection
  • Built-in microSD card slot supporting up to 256 GB of storage

AI-Powered Human and Vehicle Classification

Equipped with advanced deep learning algorithms, the IPC-B261H-MU excels in human and vehicle classification. This AI-powered feature helps improve surveillance accuracy by identifying and distinguishing targets, enabling more efficient monitoring and reducing false alerts.

Built-in Microphone for Enhanced Audio Security

The camera integrates a built-in microphone, offering real-time audio capabilities to complement video footage. This feature allows for complete situational awareness, making it a valuable addition for environments where both visual and auditory surveillance are necessary.

Weatherproof and Durable Design

Designed for demanding environments, the IPC-B261H-MU features an IP67 rating, making it both water and dust resistant. Its rugged construction ensures reliability in outdoor settings, regardless of weather conditions, making it suitable for both residential and commercial applications.

Efficient Bandwidth and Storage Management

The IPC-B261H-MU utilises H.265+ compression technology to significantly reduce bandwidth and storage requirements without compromising video quality. This efficient compression ensures long-term storage without overwhelming network infrastructure, making it an ideal choice for large-scale surveillance setups.

Easy Installation with PoE Support

The camera supports Power over Ethernet (PoE), simplifying installation by reducing the need for separate power cables. This feature streamlines the setup process and provides flexible placement options, making the camera perfect for a wide range of security systems.

Flexible Viewing Angles and Adjustable Lens

The IPC-B261H-MU offers versatile mounting options with its adjustable pan, tilt, and rotation angles. With a 2.8 mm fixed lens providing a wide field of view (107° horizontal, 57° vertical), it ensures comprehensive coverage of the monitored area. Additionally, the camera's lens is designed for optimal image clarity with an F1.6 aperture for enhanced low-light performance.

Category Specification Details
Model Version IPC-B261H-MU 6 MP Fixed Bullet Network Camera
Camera Image Sensor 1/2.8" Progressive Scan CMOS
  Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON)
B/W: 0 Lux with IR
  Shutter Speed 1/3 s to 1/100,000 s
  Wide Dynamic Range 120 dB
  Day & Night IR cut filter
  Angle Adjustment Pan: 0° to 360°
Tilt: 0° to 90°
Rotate: 0° to 360°
Lens Lens Type Fixed focal lens
  Focal Length & FOV 2.8 mm
horizontal FOV 107°
vertical FOV 57°
diagonal FOV 128°
  Aperture F1.6
Illuminator IR Wavelength 850 nm
  IR Range Up to 40 m
Video Max. Resolution 3200 × 1800
  Main Stream 50 Hz: 20 fps (3200 × 1800)
25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  Sub-Stream 50 Hz: 25 fps (1280 × 720, 960 × 540, 640 × 480, 640 × 360)
  Third Stream 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
  Compression H.265/H.264/H.264+/H.265+
Audio Audio Compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
  Audio Bit Rate 64 Kbps (G.711ulaw/G.711alaw)
16 Kbps (G.722.1)
16 Kbps (G.726)
16 Kbps to 64 Kbps (AAC)
32 to 192 Kbps (MP2L2)
8 to 320 Kbps (MP3)
  Audio Sampling Rate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  Environment Noise Filtering Yes
Network Protocols TCP/IP, ICMP, HTTP
HTTPS, FTP, DHCP
DNS, DDNS, RTP
RTSP, NTP, UPnP
SMTP, IGMP, 802.1X
QoS, IPv4, IPv6
UDP, Bonjour, SSL/TLS
PPPoE, SNMP
  Simultaneous Live View Up to 6 channels
  Security Password protection
complicated password
HTTPS encryption
IP address filter
Security Audit Log
TLS 1.1/1.2
Interface Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
  On-Board Storage MicroSD card slot
supports up to 256 GB
General Camera Material Aluminium alloy body
IR cover: plastic
  Camera Dimensions Ø 70 mm × 161.7 mm
  Package Dimensions 216 mm × 121 mm × 118 mm
  Camera Weight Approx. 485 g
  Package Weight Approx. 744 g
  Power Consumption 12 VDC
0.5 A, max. 6 W
PoE (802.3af) max. 7.2 W
  Power Supply 12 VDC ± 25%
PoE: 802.3af, Class 3
Approval EMC FCC, CE-EMC, RCM, IC, KC
  Safety UL, CB, CE-LVD, BIS
  Environment CE-RoHS
WEEE
Reach
  Protection IP67 (IEC 60529-2013)
SKU HIL.IPC-B261H-MU
Model # IPC-B261H-MU
Brand HiLook
Shipping Weight 0.7440kg
Shipping Width 0.220m
Shipping Height 0.120m
Shipping Length 0.130m
Shipping Cubic 0.003432000m3
