・Frequency range 100 kHz-30 MHz

・45 frequency memories for shorter tuning time.

Frequency coverage 1.6–30 MHz (with 7 m or longer antenna element)
Power supply requirement 13.6 V DC (supplied from the HF transceiver)
Current drain Maximum 2 A
Operating temperature range –30°C to +60°C
–20°C to +55°C (GMDSSS version)
Weight (approximately) 2.5 kg
Antenna connector SO-239 (50 Ω)
Maximum Input power 150 W (PEP) 100 W (continuous)
Automatic tuning time Approximately 2 to 3 seconds (general condition)
Maximum 15 seconds
Automatic tuning accuracy SWR 2.0:1 (after tuning, except for multiples of 1⁄2 λ)
Usable pole diameter 32 to 60 mm
IP rating IPX6
Note Version 45 must be used for MED certification compliance with the GM800.





SKU ICO.AT141_64
Model # ICO.AT141_64
Brand Icom
Shipping Weight 2.5000kg
Shipping Width 0.230m
Shipping Height 0.091m
Shipping Length 0.340m
Shipping Cubic 0.007116000m3
