Slim, Lightweight, High Performance

The IC-M25EURO has the slimmest (depth:30.5 mm) and lightest (218 g) body as a floating marine transceiver*. It also delivers uncompromised performance that will exceed expectations.
*As of July 2015, researched by Icom.

Large LCD, Simple User Interface

The IC-M25EURO’s LCD is 30% larger than its predecessor, the IC-M23 and shows clearly large channel numbers and status icons. The buttons on the front panel are well laid out and provide simple and straightforward operation.

USB Charging (Micro-B USB type)

A standard USB connector (Micro-B type) is used for charging the IC-M25EURO. Cigarette lighter cables or mobile batteries for charging smartphones or other devices can be used with the IC-M25EURO*.
* The IC-M25EURO accepts 5 V/1 A (Max.) input. Use of third-party products is not guaranteed.

Float'n Flash

The IC-M25EURO floats and lets you know where it is with the flashing red LED light and LCD/key backlight.

11 Hours of Battery Life

The built-in 1500 mAh lithium-ion battery allows 11 hours (approx.) of long operation*.
* Typical operation with Tx (Hi): Rx: standby=5:5:90

Optional Speaker-Microphone, HM-213

The optional waterproof speaker-microphone, HM-213, provides commercial-grade convenience while mounting the radio around the waist. The radio floats even when the HM-213 is attached.

550 mW Audio Output

The IC-M25EURO provides a powerful 550mW (typical) audio output and the received voice can be heard loud and clear.

Other Features

  • IPX7 waterproof construction
  • (1 m depth of water for 30 minutes)
  • 4-step battery life indicator
  • Dual/Tri-watch functions*
  • Instant access to Ch 16 or programmable call channel
  • Favorite channel function
  • Monitor function opens noise squelch
  • Auto scan function
  • LCD auto backlighting
  • AquaQuake™ draining function
  • Supports 4-digit channels

Included Accessories

  • USB charger, BC-217SE/SV*
  • Belt clip, MB-133
  • Antenna, FA-SC59V
  • Hand strap
  • Battery is built-in



General

Frequency range Tx 156.025–157.425 MHz
Rx 156.050–163.275 MHz
Usable channel groups INT, USA, CAN, WX channels
Type of emission 16K0G3E (FM)
Power supply voltage 3.7 V DC nominal
Current drain Tx 2.3 A
Rx (Internal SP/External SP) 300 mA/200 mA (Max. audio)
Operating temperature range –20°C to +60°C; –4°F to +140°F
Antenna impedance 50 Ω
Dimensions (W×H×D)
(Projections not included)		 56.6×134.2×30.5 mm;
2.2×5.3×1.2 in
Weight (approximately) 220 g; 7.7 oz
(With FA-SC59V and MB-133)

Transmitter

Output power 5 W (approximately)/1 W
Max. frequency deviation ±5.0 kHz
Frequency stability ±10 ppm
Spurious emissions –68 dBc typical
Adjacent channel power 70 dB
Residual modulation 40 dB

Receiver

Sensitivity 0.25 μV typical (at 12 dB SINAD)
Squelch sensitivity 0.25 μV typical (at threshold)
Adjacent channel selectivity 70 dB typical
Spurious response 70 dB typical
Intermodulation 70 dB typical
Audio output power
(at 10% distortion)		 Internal SP 550 mW typical (12 Ω load)
External SP 300 mW typical (4 Ω load)
SKU ICO.IC-M25-G
Model # IC-M25EURO
Brand Icom
Shipping Weight 0.5000kg
Shipping Width 0.056m
Shipping Height 0.030m
Shipping Length 0.134m
Shipping Cubic 0.000225000m3
Unit Of Measure ea
