Features

  • Red reverse polarity indicating LED
  • All hot neutral and safety ground buses installed fully pre-wired
  • All circuit label positions are backlit on standard panels - No kit required
  • "ON"" indicating LEDs installed in all circuit positions
  • Maximum panel amperage - 50 Amperes
  • MIL-C-5541C or equivalent immersion undercoating for lifetime corrosion resistance
  • Two-part polyurethane slate gray finish
  • Heavy 1/8"" aluminum 5052 alloy
  • Industry standard height and width
  • Countersunk mounting holes throughout
  • Detailed installation instructions and cutout template included
  • Includes set of 30 common Large Format Labels
  • Over 500 individual Labels available
  • "

Specifications

Positions: 6

Nominal Voltage: 230V AC

Height   7.50in (190.5 mm)

Width   5.25in (133.35 mm)

Weight 1.87lb (0.85 kg)

SKU BSS.8127
Model # 8127
UPC/EAN 632085081270
Brand Blue Sea Systems
Shipping Weight 0.8500kg
