Features

  • Will withstand the water exposures normally encountered in above deck applications: salt spray rain hose washdowns momentary immersions
  • ON-OFF Contura Switches
  • ON indicating LEDs embedded in switches
  • Watertight mounting gasket included
  • Countersunk mounting holes throughout
  • Heavy 1/10"aluminum material
  • Two-part polyurethane slate gray finish
  • Industry standard height and width
  • Mil-Spec chemical treatment via immersion to protect every surface detail from corrosion
  • Completely wired and ready to install
  • Includes set of 60 labels

NOTE: Waterproof panel labels are not backlit

Specifications
Weatherproof  Water Resistant
Positions 4
Nominal Voltage 12V DC
24V DC
Panel Cumulative Rating 45A
Switch Rating 20A @ 12V DC
15A @ 24V DC
Height 3.75in (95.25 mm)
Width 5.25in (133.35 mm)
Depth 3.00in (76.2 mm)
Weight 0.75Lb (0.34 Kg)
Weight 0.75lb (0.34 kg)



SKU BSS.8262
Model # 8262
UPC/EAN 632085082628
Brand Blue Sea Systems
Shipping Weight 0.3400kg
