Victron MultiPlus 24/2000/50-32 230V VE.Bus Inverter/Charger
Victron MultiPlus 230 Volt AC, 24 Volt 2000VA (1600W at 0.8PF) Inverter Charger with 50 Amp battery charging and 32 Amp AC transfer capability. Compatible with all batteries including Lithium.
SKU: VIC.PMP242200000 | MPN: PMP242200000
SAVE 33%!
Available at Victron
In Stock at Victrons Australian warehouse and typically ships within 5-6 Business Days.
The MultiPlus is an Inverter and Charger combination supporting easy installation by way of the Victron MK3-USB interface cable, including the following features:
- True sine wave inverter
- Adaptive charging
- Hybrid PowerAssist
- PowerControl
- Multiple system integration
Multifunctional, with intelligent power management
The MultiPlus is a powerful true sine wave inverter, a sophisticated battery charger that features adaptive charge technology, and a high-speed AC transfer switch in a single compact enclosure. Next to these primary functions, the MultiPlus has several advanced features, as outlined below.
Parallel operation and three phase capability
Up to six Multis can operate in parallel to achieve higher power output. In addition to parallel connection, three units can be configured for three-phase output.
PowerControl - Dealing with limited generator, shore side or grid power
With the Multi Control Panel a maximum generator or shore current can be set. The MultiPlus will then take account of other AC loads and use whatever is extra for charging, thus preventing the generator or shore supply from being overloaded.
PowerAssist - Boosting the capacity of shore or generator power
This feature takes the principle of PowerControl to a further dimension. It allows the MultiPlus to supplement the capacity of the alternative source. Where peak power is so often required only for a limited period, the MultiPlus will make sure that insufficient shore or generator power is immediately compensated for by power from the battery. When the load reduces, the spare power is used to recharge the battery.
Four stage adaptive charger and dual bank battery charging
The main output provides a powerful charge to the battery system by means of advanced ‘adaptive charge’ software. The software fine-tunes the three-stage automatic process to suit the condition of the battery, and adds a fourth stage for long periods of float charging. The adaptive charge process is described in more detail on the Phoenix Charger datasheet and on our website, under Technical Information. In addition to this, the MultiPlus will charge a second battery using an independent trickle charge output intended for a main engine or generator starter battery.
High start-up power
Needed to start high inrush loads such as power converters for LED lamps, halogen lamps or electric tools.
Search Mode
When Search Mode is ‘on’, the power consumption of the inverter in no-load operation is decreased by approx. 70%. In this mode the Multi, when operating in inverter mode, is switched off in case of no load or very low load, and switches on every two seconds for a short period. If the output current exceeds a set level, the inverter will continue to operate. If not, the inverter will shut down again.
Programmable relay
By default, the programmable relay is set as an alarm relay, i.e. the relay will de-energise in the event of an alarm or a pre-alarm (inverter almost too hot, ripple on the input almost too high, battery voltage almost too low).
Remote on / off / charger on
Three pole connector to mount an external remote if required.
Remote configuring and monitoring
Install a Cerbo GX or other GX product to connect to the internet. Operational data can be stored and displayed on Victrons Free VRM (Victron Remote Management) website, free of charge.When connected to the internet, systems can be accessed remotely, and settings can be changed.
The basics of using VE Configure
MultiPlus 24/2000/50 | |
PowerControl / PowerAssist | YES |
Three Phase and parallel operation | YES |
Transfer switch | 35A |
INVERTER | |
Input voltage range | 19 - 33V |
Output | Output voltage: 230VAC ± 2% Frequency: 50Hz ± 0,1% (1) |
Cont. output power at 25°C (3) | 2000VA |
Cont. output power at 25°C | 1600W |
Cont. output power at 40°C | 1400W |
Cont. output power at 65°C | 1000W |
Peak power | 3500 W |
Maximum efficiency | 94% |
Zero-load power | 9W |
Zero-load power in search mode | 3W |
CHARGER | |
AC Input | Input voltage range: 187-265 VAC Input frequency: 45 –65 Hz |
Charge voltage 'absorption' | 28.8V |
Charge voltage 'float' | 27.6V |
Storage mode | 26.4V |
Charge current house battery (4) | 50A |
Charge current starter battery | 1A |
Battery temperature sensor | YES |
GENERAL | |
Programmable relay (5) | YES |
Protection | Output short circuit Overload Battery voltage too high Battery voltage too low Temperature too high 230VAC on inverter output Input voltage ripple too high |
VE.Bus communication port | For parallel and three phase operation, remote monitoring and system integration |
Remote on-off | On/Off |
DIP switches | Battery charge voltage / search mode |
Internal DC fuse | NO |
Common Characteristics | Operating temp. range: -40 to +65°C (fan assisted cooling)Humidity (non-condensing): max 95% |
ENCLOSURE | |
Common Characteristics | Material & Colour: Steel(RAL 5012) / Protection Level: IP22 |
Battery-connection | M8 Bolts |
230V AC-connection | Screw |
Weight | 13.5KG |
Dimensions (h x w x d) | 500 x 225 x 135 mm |
STANDARDS | |
Safety | EN-IEC 60335-1, EN-IEC 60335-2-29, EN 62109-1 |
Emission Immunity | EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 |
Automotive Directive | ECE R10-5 |
NOTES | |
1) Can be adjusted to 60Hz and to 240V |
SKU | VIC.PMP242200000 |
Model # | PMP242200000 |
UPC/EAN | 8719076052173 |
Brand | Victron Energy |
Shipping Weight | 17.5000kg |
Shipping Width | 0.240m |
Shipping Height | 0.330m |
Shipping Length | 0.590m |
Shipping Cubic | 0.046728000m3 |
Unit Of Measure | ea |
Purchase with confidence knowing your product is covered by the Victron 5-year manufacturer warranty.
